WCF开发框架之Winform客户端配置文件 - App.config
WCF开发框架之Winform客户端配置文件 - App.config
WCF开发框架之Winform客户端配置文件 - App.config
App.Config文件
文件说明
提供三种常用绑定方式：wsHttpBinding，basicHttpBinding，netTcpBinding 提供标准的行为配置：<behavior name="myBehavior"> 支持http/https协议：security mode 支持https自定义证书：clientCredentialsXML Code:
<?xml version="1.0" encoding="utf-8"?>
<configuration>
<configSections>
<sectionGroup name="system.data.dataset.serialization" type="System.Data.SerializationSettingsSectionGroup, System.Data, Version=4.0.0.0, Culture=neutral, PublicKeyToken=b77a5c561934e089">
<section name="allowedTypes" type="System.Data.AllowedTypesSectionHandler, System.Data, Version=4.0.0.0, Culture=neutral, PublicKeyToken=b77a5c561934e089"/>
</sectionGroup>
</configSections>
<system.data.dataset.serialization>
<allowedTypes>
<!-- <add type="assembly qualified type name" /> -->
<add type="MySql.Data.Types.MySqlDateTime, MySql.Data, Version=6.9.9.0, Culture=neutral, PublicKeyToken=c5687fc88969c44d" />
<!-- additional <add /> elements as needed -->
</allowedTypes>
</system.data.dataset.serialization>
<startup>
<supportedRuntime version="v4.0" sku=".NETFramework,Version=v4.5"/>
</startup>
<appSettings>
<!--【此配置已取消】：是否使用HTTPS协议 true/false -->
<!-- WCFFactory.Create<T>方法使用：-->
<!-- 1.若WCF服务器基于https协议,必须设置为：true -->
<!-- 2.开发环境(本地测试)设置为：false -->
<add key="UseHttps" value="false"/>
<!--支持4种凭据类型：None/Basic/Windows/Certificate-->
<!--默认为None，不需要凭据-->
<add key="UseCredentials" value="None"/>
<!--SSL证书密码-->
<add key="SSLPassword" value="V6gTKX+nZUB+5imSHNpMTg=="/>
<!--Basic/Windows凭据账号和密码,请使用KeyProvider.Default.Decrypt解密-->
<add key="Windows_UserName" value="HS+AHKm26rokVfWqabT5TA=="/>
<add key="Windows_Password" value="Snj6+Q3dGGb1ukbEi0igFw=="/>
<!--开发环境(本地测试)：IIS承载的WCF服务地址（HTTP）协议,支持：wsHttpBinding/basicHttpBinding两种协议-->
<add key="ICommonService" value="http://localhost:23270/CommonService.svc"/>
<add key="IDataDictService" value="http://localhost:23270/DataDictService.svc"/>
<add key="IMessageCenter" value="http://localhost:23270/MessageCenter.svc"/>
<add key="ISystemSecurityService" value="http://localhost:23270/SystemSecurityService.svc"/>
<add key="IAccountModuleService" value="http://localhost:23270/AccountModuleService.svc"/>
<add key="IPurchaseModuleService" value="http://localhost:23270/PurchaseModuleService.svc"/>
<add key="ISalesModuleService" value="http://localhost:23270/SalesModuleService.svc"/>
<add key="IInventoryModuleService" value="http://localhost:23270/InventoryModuleService.svc"/>
<add key="IHR" value="http://localhost:23270/HR.svc"/>
<!--正式环境(发布部署)：IIS承载的WCF服务地址（HTTPS）协议，CSFramework阿里云测试服务器-->
<!--
<add key="ICommonService" value="https://cs5.manonwo.com/CommonService.svc"/>
<add key="IDataDictService" value="https://cs5.manonwo.com/DataDictService.svc"/>
<add key="IMessageCenter" value="https://cs5.manonwo.com/MessageCenter.svc"/>
<add key="ISystemSecurityService" value="https://cs5.manonwo.com/SystemSecurityService.svc"/>
-->
</appSettings>
<!--WCF服务-客户端配置-->
<system.serviceModel>
<bindings>
<!--WSHttpBinding 绑定配置-->
<wsHttpBinding>
<binding name="WSHttpBinding" closeTimeout="00:10:00" openTimeout="00:10:00" receiveTimeout="00:10:00" sendTimeout="00:10:00"
bypassProxyOnLocal="false" transactionFlow="false" hostNameComparisonMode="StrongWildcard"
maxBufferPoolSize="2147483647" maxReceivedMessageSize="2147483647" messageEncoding="Text" textEncoding="utf-8" useDefaultWebProxy="true" allowCookies="false">
<readerQuotas maxDepth="2147483647" maxStringContentLength="2147483647" maxArrayLength="2147483647" maxBytesPerRead="2147483647" maxNameTableCharCount="2147483647" />
<reliableSession ordered="true" inactivityTimeout="00:10:00" enabled="false" />
<!--HTTP协议:<security mode="None"> -->
<!--HTTPS协议:<security mode="Transport"> -->
<!--默认http协议+Message安全模式+Windows认证-->
<security mode="Message">
<transport clientCredentialType="Windows" proxyCredentialType="None" />
<!--若安全模式=Message，negotiateServiceCredential必须设置true-->
<message clientCredentialType="Windows"
negotiateServiceCredential="true"
establishSecurityContext="false" />
</security>
</binding>
</wsHttpBinding>
<!--BasicHttpBinding 绑定配置-->
<basicHttpBinding>
<binding name="BasicHttpBinding" closeTimeout="00:10:00" openTimeout="00:10:00" receiveTimeout="00:10:00" sendTimeout="00:10:00"
allowCookies="false" bypassProxyOnLocal="false" hostNameComparisonMode="StrongWildcard"
maxBufferSize="2147483647" maxBufferPoolSize="2147483647" maxReceivedMessageSize="2147483647"
messageEncoding="Text" textEncoding="utf-8" transferMode="Buffered" useDefaultWebProxy="true">
<readerQuotas maxDepth="2147483647" maxStringContentLength="2147483647" maxArrayLength="2147483647" maxBytesPerRead="2147483647" />
<security mode="Message">
<transport clientCredentialType="Windows" proxyCredentialType="None" realm="" />
<message clientCredentialType="UserName" algorithmSuite="Default" />
</security>
</binding>
</basicHttpBinding>
<!--NetTcpBinding 绑定配置-->
<netTcpBinding>
<binding name="NetTcpBinding" closeTimeout="00:10:00"
openTimeout="00:10:00" receiveTimeout="00:10:00" sendTimeout="00:10:00"
transactionFlow="false" transferMode="Buffered" transactionProtocol="OleTransactions"
hostNameComparisonMode="StrongWildcard" listenBacklog="10" maxBufferPoolSize="2147483647"
maxBufferSize="2147483647" maxConnections="10" maxReceivedMessageSize="2147483647">
<readerQuotas maxDepth="2147483647" maxStringContentLength="2147483647"
maxArrayLength="2147483647" maxBytesPerRead="2147483647" maxNameTableCharCount="2147483647" />
<reliableSession ordered="true" inactivityTimeout="00:10:00"
enabled="false" />
<security mode="Message">
<transport clientCredentialType="Windows" protectionLevel="None"/>
<message clientCredentialType="Windows" />
</security>
</binding>
</netTcpBinding>
</bindings>
<!--endpoint的行为配置:behaviorConfiguration-->
<!--用于Certificate认证模式:配置客户端SSL证书信息-->
<!--1.添加服务应用方式，可通过此配置信息设置WCF行为，参考WCFTester里面的例子-->
<!--2.透明代理工厂，加载SSL证书文件，参考WCFFactory.CreateCertificate<T>-->
<behaviors>
<endpointBehaviors>
<behavior name="SSL_ClientBehavior">
<clientCredentials>
<clientCertificate
findValue="cs5.manonwo.com"
storeLocation="LocalMachine"
x509FindType="FindBySubjectName"
storeName="My"/>
<serviceCertificate>
<authentication certificateValidationMode="PeerOrChainTrust"/>
</serviceCertificate>
</clientCredentials>
</behavior>
</endpointBehaviors>
</behaviors>
</system.serviceModel>
</configuration>
//来源:C/S框架网 | www.csframework.com | QQ:23404761
<configuration>
<configSections>
<sectionGroup name="system.data.dataset.serialization" type="System.Data.SerializationSettingsSectionGroup, System.Data, Version=4.0.0.0, Culture=neutral, PublicKeyToken=b77a5c561934e089">
<section name="allowedTypes" type="System.Data.AllowedTypesSectionHandler, System.Data, Version=4.0.0.0, Culture=neutral, PublicKeyToken=b77a5c561934e089"/>
</sectionGroup>
</configSections>
<system.data.dataset.serialization>
<allowedTypes>
<!-- <add type="assembly qualified type name" /> -->
<add type="MySql.Data.Types.MySqlDateTime, MySql.Data, Version=6.9.9.0, Culture=neutral, PublicKeyToken=c5687fc88969c44d" />
<!-- additional <add /> elements as needed -->
</allowedTypes>
</system.data.dataset.serialization>
<startup>
<supportedRuntime version="v4.0" sku=".NETFramework,Version=v4.5"/>
</startup>
<appSettings>
<!--【此配置已取消】：是否使用HTTPS协议 true/false -->
<!-- WCFFactory.Create<T>方法使用：-->
<!-- 1.若WCF服务器基于https协议,必须设置为：true -->
<!-- 2.开发环境(本地测试)设置为：false -->
<add key="UseHttps" value="false"/>
<!--支持4种凭据类型：None/Basic/Windows/Certificate-->
<!--默认为None，不需要凭据-->
<add key="UseCredentials" value="None"/>
<!--SSL证书密码-->
<add key="SSLPassword" value="V6gTKX+nZUB+5imSHNpMTg=="/>
<!--Basic/Windows凭据账号和密码,请使用KeyProvider.Default.Decrypt解密-->
<add key="Windows_UserName" value="HS+AHKm26rokVfWqabT5TA=="/>
<add key="Windows_Password" value="Snj6+Q3dGGb1ukbEi0igFw=="/>
<!--开发环境(本地测试)：IIS承载的WCF服务地址（HTTP）协议,支持：wsHttpBinding/basicHttpBinding两种协议-->
<add key="ICommonService" value="http://localhost:23270/CommonService.svc"/>
<add key="IDataDictService" value="http://localhost:23270/DataDictService.svc"/>
<add key="IMessageCenter" value="http://localhost:23270/MessageCenter.svc"/>
<add key="ISystemSecurityService" value="http://localhost:23270/SystemSecurityService.svc"/>
<add key="IAccountModuleService" value="http://localhost:23270/AccountModuleService.svc"/>
<add key="IPurchaseModuleService" value="http://localhost:23270/PurchaseModuleService.svc"/>
<add key="ISalesModuleService" value="http://localhost:23270/SalesModuleService.svc"/>
<add key="IInventoryModuleService" value="http://localhost:23270/InventoryModuleService.svc"/>
<add key="IHR" value="http://localhost:23270/HR.svc"/>
<!--正式环境(发布部署)：IIS承载的WCF服务地址（HTTPS）协议，CSFramework阿里云测试服务器-->
<!--
<add key="ICommonService" value="https://cs5.manonwo.com/CommonService.svc"/>
<add key="IDataDictService" value="https://cs5.manonwo.com/DataDictService.svc"/>
<add key="IMessageCenter" value="https://cs5.manonwo.com/MessageCenter.svc"/>
<add key="ISystemSecurityService" value="https://cs5.manonwo.com/SystemSecurityService.svc"/>
-->
</appSettings>
<!--WCF服务-客户端配置-->
<system.serviceModel>
<bindings>
<!--WSHttpBinding 绑定配置-->
<wsHttpBinding>
<binding name="WSHttpBinding" closeTimeout="00:10:00" openTimeout="00:10:00" receiveTimeout="00:10:00" sendTimeout="00:10:00"
bypassProxyOnLocal="false" transactionFlow="false" hostNameComparisonMode="StrongWildcard"
maxBufferPoolSize="2147483647" maxReceivedMessageSize="2147483647" messageEncoding="Text" textEncoding="utf-8" useDefaultWebProxy="true" allowCookies="false">
<readerQuotas maxDepth="2147483647" maxStringContentLength="2147483647" maxArrayLength="2147483647" maxBytesPerRead="2147483647" maxNameTableCharCount="2147483647" />
<reliableSession ordered="true" inactivityTimeout="00:10:00" enabled="false" />
<!--HTTP协议:<security mode="None"> -->
<!--HTTPS协议:<security mode="Transport"> -->
<!--默认http协议+Message安全模式+Windows认证-->
<security mode="Message">
<transport clientCredentialType="Windows" proxyCredentialType="None" />
<!--若安全模式=Message，negotiateServiceCredential必须设置true-->
<message clientCredentialType="Windows"
negotiateServiceCredential="true"
establishSecurityContext="false" />
</security>
</binding>
</wsHttpBinding>
<!--BasicHttpBinding 绑定配置-->
<basicHttpBinding>
<binding name="BasicHttpBinding" closeTimeout="00:10:00" openTimeout="00:10:00" receiveTimeout="00:10:00" sendTimeout="00:10:00"
allowCookies="false" bypassProxyOnLocal="false" hostNameComparisonMode="StrongWildcard"
maxBufferSize="2147483647" maxBufferPoolSize="2147483647" maxReceivedMessageSize="2147483647"
messageEncoding="Text" textEncoding="utf-8" transferMode="Buffered" useDefaultWebProxy="true">
<readerQuotas maxDepth="2147483647" maxStringContentLength="2147483647" maxArrayLength="2147483647" maxBytesPerRead="2147483647" />
<security mode="Message">
<transport clientCredentialType="Windows" proxyCredentialType="None" realm="" />
<message clientCredentialType="UserName" algorithmSuite="Default" />
</security>
</binding>
</basicHttpBinding>
<!--NetTcpBinding 绑定配置-->
<netTcpBinding>
<binding name="NetTcpBinding" closeTimeout="00:10:00"
openTimeout="00:10:00" receiveTimeout="00:10:00" sendTimeout="00:10:00"
transactionFlow="false" transferMode="Buffered" transactionProtocol="OleTransactions"
hostNameComparisonMode="StrongWildcard" listenBacklog="10" maxBufferPoolSize="2147483647"
maxBufferSize="2147483647" maxConnections="10" maxReceivedMessageSize="2147483647">
<readerQuotas maxDepth="2147483647" maxStringContentLength="2147483647"
maxArrayLength="2147483647" maxBytesPerRead="2147483647" maxNameTableCharCount="2147483647" />
<reliableSession ordered="true" inactivityTimeout="00:10:00"
enabled="false" />
<security mode="Message">
<transport clientCredentialType="Windows" protectionLevel="None"/>
<message clientCredentialType="Windows" />
</security>
</binding>
</netTcpBinding>
</bindings>
<!--endpoint的行为配置:behaviorConfiguration-->
<!--用于Certificate认证模式:配置客户端SSL证书信息-->
<!--1.添加服务应用方式，可通过此配置信息设置WCF行为，参考WCFTester里面的例子-->
<!--2.透明代理工厂，加载SSL证书文件，参考WCFFactory.CreateCertificate<T>-->
<behaviors>
<endpointBehaviors>
<behavior name="SSL_ClientBehavior">
<clientCredentials>
<clientCertificate
findValue="cs5.manonwo.com"
storeLocation="LocalMachine"
x509FindType="FindBySubjectName"
storeName="My"/>
<serviceCertificate>
<authentication certificateValidationMode="PeerOrChainTrust"/>
</serviceCertificate>
</clientCredentials>
</behavior>
</endpointBehaviors>
</behaviors>
</system.serviceModel>
</configuration>
//来源:C/S框架网 | www.csframework.com | QQ:23404761
参考文档：
WCF开发框架之WSHttpBinding参数配置(C#代码配置+App.Config两种方案)
Winform企业级WCF快速开发框架平台(C/S架构+WCF+DevExpress+SQL多数据库)
Winform界面开发框架之界面展示效果图|C/S框架网
WCF开发框架之WCF服务器配置文件 - Web.config
WCF开发框架之ICommunicationObject 对象详解
基于Winform三层架构+WCF+ORM模型的快速开发框架
Winform快速开发框架之存储图片资源解决方案|C/S框架网
Winform快速开发框架之权限系统设计(3) - 功能按钮权限控制基本原理
Winform快速开发框架之权限系统设计(2) - 功能模块介绍
Winform快速开发框架之权限系统设计(1) - 基本概述
winform界面布局设计和WCF的应用方面，你对这方面研究多吗？
WCF App.Config 配置参数详解：OpenTimeout, CloseTimeout, SendTimeout, ReceiveTimeout
WCF开发框架配置详解 WCF开发实例高级教程
Winform三层架构+WebService+权限管理系统软件开发平台（C#.NET开发）
WCF开发框架默认连接：HTTP协议+Message安全模式+Windows客户端认证
WCF顶级安全:HTTPS协议SSL证书+Windows认证+TransportWithMessageCredential安全模式
WCF开发框架之WSHttpBinding参数配置(C#代码配置+App.Config两种方案)
Winform企业级WCF快速开发框架平台(C/S架构+WCF+DevExpress+SQL多数据库)
Winform界面开发框架之界面展示效果图|C/S框架网
WCF开发框架之WCF服务器配置文件 - Web.config
WCF开发框架之ICommunicationObject 对象详解
基于Winform三层架构+WCF+ORM模型的快速开发框架
Winform快速开发框架之存储图片资源解决方案|C/S框架网
Winform快速开发框架之权限系统设计(3) - 功能按钮权限控制基本原理
Winform快速开发框架之权限系统设计(2) - 功能模块介绍
Winform快速开发框架之权限系统设计(1) - 基本概述
winform界面布局设计和WCF的应用方面，你对这方面研究多吗？
WCF App.Config 配置参数详解：OpenTimeout, CloseTimeout, SendTimeout, ReceiveTimeout
WCF开发框架配置详解 WCF开发实例高级教程
Winform三层架构+WebService+权限管理系统软件开发平台（C#.NET开发）
WCF开发框架默认连接：HTTP协议+Message安全模式+Windows客户端认证
WCF顶级安全:HTTPS协议SSL证书+Windows认证+TransportWithMessageCredential安全模式
其它资料：
什么是C/S结构？ | C/S框架核心组成部分 | C/S框架-WebService部署图 | C/S框架-权限管理 | C/S结构系统框架 - 5.1旗舰版介绍 | C/S结构系统框架 - 功能介绍 | C/S结构系统框架 - 产品列表 | C/S结构系统框架 - 应用展示(图) | 三层体系架构详解 | C/S架构轻量级快速开发框架 | C/S框架网客户案例 | WebApi快速开发框架 | C/S框架代码生成器 | 用户授权注册软件系统 | 版本自动升级软件 | 数据库底层应用框架 | CSFramework.CMS内容管理系统 |
什么是C/S结构？ | C/S框架核心组成部分 | C/S框架-WebService部署图 | C/S框架-权限管理 | C/S结构系统框架 - 5.1旗舰版介绍 | C/S结构系统框架 - 功能介绍 | C/S结构系统框架 - 产品列表 | C/S结构系统框架 - 应用展示(图) | 三层体系架构详解 | C/S架构轻量级快速开发框架 | C/S框架网客户案例 | WebApi快速开发框架 | C/S框架代码生成器 | 用户授权注册软件系统 | 版本自动升级软件 | 数据库底层应用框架 | CSFramework.CMS内容管理系统 |
